½ºÅ͵å°æ
(Stud
diameter)
G
mm
ȣĪ¹øÈ£ (Bearing No.) Áú ·® (Mass)
gr.
ÁÖ ¿ä Ä¡ ¼ö (Dimensions) mm
¾Á ¾øÀ½ (Unsealed) ¾Á ºÎÂø (Sealed)
¿øÅë¿Ü·û (Cylindrical outer ring) ±¸¸é¿Ü·û (Crowned outer ring) ¿øÅë¿Ü·û (Cylindrical outer ring) ±¸¸é¿Ü·û (Crowned outer ring) H D ³ª »ç (Thread sizes) S
CF.. CF..R CF..UU CF..UUR
5
CF 5
CF 5R
CF 5 UU
CF 5 UUR
10.5
3
13
M 5 x 0.8
6 CF 6 CF 6R CF 6 UU CF 6 UUR 18.5 3 16 M 6 x 1
8 CF 8 CF 8R CF 8 UU CF 8 UUR 28.5 4 19 M 8 x 1.25
10 CF 10 CF 10R CF 10 UU CF 10 UUR 45 4 22 M 10 x 1.25
CF 10-1 CF 10-1R CF 10-1 UU CF 10-1 UUR 60 26
12 CF 12 CF 12R CF 12 UU CF 12 UUR 95 6 30 M 12 x 1.5
CF12-1 CF 12-1R CF12-1 UU CF12-1 UUR 105 32
16 CF 16 CF 16R CF 16 UU CF 16 UUR 170 6 35 M 16 x 1.5
18 CF 18 CF 18R CF 18 UU CF 18 UUR 250 8 40 M 18 x 1.5
20 CF 20 CF 20R CF 20 UU CF 20 UUR 460 8 52 M 20 x 1.5
CF 20-1 CF 20-1R CF 20-1 UU CF 20-1 UUR 385 47
24 CF 24 CF 24R CF 24 UU CF 24 UUR 815 8 62 M 24 x 1.5
CF 24-1 CF 24-1R CF 24-1 UU CF 24-1 UUR 1140 72
30 CF 30 CF 30R CF 30 UU CF 30 UUR 1870 8 80 M 30 x 1.5
CF 30-1 CF 30-1R CF 30-1 UU CF 30-1 UUR 2030 85
CF 30-2 CF 30-2R CF 30-2 UU CF 30-2 UUR 2220 90

ÁÖ ¿ä Ä¡ ¼ö (Dimensions) mm ¼³Ä¡Ä¡¼ö
f
ÃÖ¼Ò
(Minimum Clamping Diameter) mm
±â º»
µ¿Á¤°Ý ÇÏÁß (Basic dynamic load ratings) C/kgf
±â º»
Á¤Á¤°Ý ÇÏÁß (Basic static load ratings) Co/kgf
Çã ¿ë
ȸÀü¼ö
(Limiting speed)
rpm
B B1 B3 M g1 G1 B2 r
9
10
23


7.5

0.5
9.7
280
180
29000
11 12 28     9   0.5 11 270 170 25000
11 12 32     11   0.5 13 300 210 20000
12 13 36     13   1 15 410 320 17000
14 15 40 M6 x 1 3 14 6 1.5 20 590 450 14000
18 19.5 52 M6 x 1 3 18 8 1.5 24 850 760 10000
20 21.5 58 M6 x 1 3 20 10 1.5 26 1180 1220 8500
24 25.5 66 M6 x 1 4 22 12 1.5 36 1630 1690 7000
29 30.5 80 M6 x 1 4 25 12 1.5 40 2160 2210 6500
35 37 100 M6 x 1 4 32 15 2 46 2830 3700 5000
